Gimbal
|
|
|
Supported DJI Gimbals:
|
Zenmuse H30
Zenmuse H30T
Zenmuse H20 Series
Zenmuse P1
Zenmuse L1
Zenmuse L2 |
|
Ingress Protection Rating:
|
IP55 |
|
GNSS:
|
GPS + GLONASS + BeiDou + Galileo |
|
Operating Temperature:
|
-20° to 50° C (-4° to 122° F) |
Remote Controller
|
|
|
Screen:
|
7.02-inch LCD touchscreen
Resolution: 1920×1200
Max brightness: 1200 nits |
|
Weight:
|
Approx. 1.25 kg (without WB37 battery) Approx. 1.42 kg (with WB37 battery) |
|
Built-in Battery:
|
Li-ion (6500 mAh@7.2 V)
For charging use the battery station or USB-C fast charger with a max power of 65 W (max voltage of 20 V)
Charging Time: 2 hours
Chemical System: LiNiCoAlO2 |
|
External Battery:
|
(WB37 Intelligent Battery): Capacity 4920 mAh
Voltage 7.6 V
Li-ion
Energy 37.39 Wh
Chemical System LiCoO2 |
|
Operating Time:
|
(Built-in Battery) Approx. 3.3 hours |
|
Operating Time:
|
(Built-in + External Battery) Approx. 6 hours |
|
Operating Temperature:
|
-20° to 50° C (-4° to 122° F) |
|
Operating Frequency:
|
2.4000-2.4835 GHz
5.725-5.850 GHz |
|
Transmitter Power:
|
(EIRP) 2.4000-2.4835 GHz: < 33 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
5.725-5.850 GHz: < 33 dBm (FCC), < 14 dBm (CE), < 23 dBm (SRRC) |
|
Wi-Fi Protocol:
|
Wi-Fi 6 |
|
Wi-Fi Operating Frequency:
|
2.4000-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz |
|
Bluetooth Protocol:
|
Bluetooth 5.1 |
|
Bluetooth Operating Frequency:
|
2.4000-2.4835 GHz |
Video Transmission
|
|
|
Video Transmission System:
|
DJI O3 Enterprise Transmission |
|
Antenna:
|
4 video transmission antennas, 2T4R |
|
Max Transmission Distance:
|
(Obstructed, free of interference) 20 km (FCC) | 8 km (CE/SRRC/MIC) |
|
Max Transmission Distance:
|
(With interference) Approx. 0-0.5 km (Low Interference and Obstructed by Buildings)
Approx. 0.5-3 km (Low Interference and Obstructed by Trees)
Approx. 1.5-3 km (Strong Interference and Unobstructed, urban landscape)
Approx. 3-9 km (Medium Interference and Unobstructed, suburban landscape)
Approx. 9-20 km (Low Interference and Unobstructed, suburb/seaside) |
Video System
|
|
|
Obstacle Sensing Range:
|
(Forward/Backward/Left/Right): 0.7-40 m |
|
Obstacle Sensing Range:
|
(Upward/Downward): 0.6-30 m |
|
FOV:
|
(Forward/Backward/Downward): 65° (horizontal) | 50° (vertical) |
|
FOV:
|
(Left/Right/Upward): 75° (horizontal) | 60° (vertical) |
|
Operating Environment:
|
Surfaces with discernible patterns and adequate lighting (lux > 15) |
Infrared Sensing System
|
|
|
Obstacle Sensing Range:
|
0.1-8 m |
|
FOV:
|
30° (±15°) |
|
Operating Environment:
|
Large, diffuse, and reflective obstacles (reflectivity > 10%) |
LED Auxiliary Light
|
|
|
Effective Illumination Distance:
|
5m |
|
Illumination Type:
|
60 Hz, solid glow |
FPV Camera
|
|
|
Resolution:
|
1080p |
|
FOV:
|
142° |
|
Frame Rate:
|
30fps |
Intelligent Flight Battery
|
|
|
Model:
|
TB65 |
|
Capacity:
|
5880 mAh |
|
Voltage:
|
44.76 V |
|
Type:
|
Li-ion |
|
Energy:
|
263.2 Wh |
|
Weight:
|
Approx. 1.35 kg |
|
Operating Temperature:
|
-20° to 50° C (-4° to 122° F) |
|
Ideal Storage Temperature:
|
22° to 30° C (71.6° to 86° F) |
|
Charging Temperature:
|
-20° to 40° C (-4° to 104° F)
When the ambient temperature is below 5° C (41° F), the battery will trigger the auto-heating function. Charging at low temperatures may reduce battery life. It is recommended to charge at 15° to 35° C (59° to 95° F) |
|
Charging Time:
|
With a 220V power supply, it takes approximately 60 minutes to fully charge two TB65 Intelligent Flight Batteries and approximately 30 minutes to charge them from 20% to 90%.
With a 110V power supply, it takes approximately 70 minutes to fully charge two TB65 Intelligent Flight Batteries and approximately 40 minutes to charge them from 20% to 90% |
Intelligent Battery Station
|
|
|
Dimensions:
|
(L×W×H): 580×358×254 mm |
|
Net Weight:
|
Approx. 8.98 kg |
|
Compatible Stored Items:
|
Eight TB65 Intelligent Flight Batteries
Four WB37 Intelligent Batteries |
|
Input Voltage:
|
100-120 VAC, 50-60 Hz
220-240 VAC, 50-60 Hz |
|
Max Input Power:
|
1070 W |
|
Output Power:
|
100-120 V, 750 W
220-240 V, 992 W |
|
Operating Temperature:
|
-20° to 40° C (-4° to 104° F) |
