Unitree B2 - Quadruped Robot


Price:
Sale price£52,899.00

Inc. VAT

Finance and business invoice options available

Description

The Unitree B2 is the recently launched top-line model of Unitree's industrial-grade quadruped robots. Unitree has introduced various performance enhancements in B2 compared to its previous model, Unitree B1. The overall performance of Unitree B2, including load capacity, range, motion capabilities, and speed, is two to three times that of existing quadruped robots globally.

The Unitree B2 is the fastest running industrial-grade quadruped robot with running speed of 6m/s. Its excellent terrain adaptability ensures stable travel on slippery or uneven surfaces, which allows it to cope with a variety of environments.

The Unitree B2 navigates stairs with ease, demonstrating outstanding sustained climbing abilities while effortlessly tackling steps, all while maintaining exceptional stability and balance. B2 also comes with superior obstacle-crossing ability, and can easily cross the mess of wood piles, 40cm high platforms and other obstacles.

The B2's extreme performance provides greater flexibility and stability for industrial operations as there is a 170% increase in the joint performance of Unitree B2, with 360 N.m of torque. The Unitree B2 boasts a 100% increase in continuous walking endurance with a load exceeding 40kg, allowing for more than 4 hours of continuous walking with a 20kg load and covering over 15km. Furthermore, it achieves a remarkable 200% increase in endurance, showcasing an unloaded continuous walking endurance of over 5 hours and covering more than 20km in distance.

The Unitree B2's innovative structural design facilitates seamless transitions between legged and wheeled forms, offering versatility and adaptability as needed. The B2's battery features swift replacement capabilities and is compatible with autonomous charging solutions if desired, making it adaptable for a diverse array of applications.

With versatile industrial applications, the B2 is designed for tasks like inspections, infrared scanning, 3D mapping, optimized environmental perception, power inspections, and intelligent power solutions, showcasing its adaptability across various industries. The Unitree B2 also excels in emergency rescue operations, effortlessly navigating challenging terrains such as long stairs, rock piles, and steep slopes.

Specifications

Product Details



Dimensions:

(Standing) 1098mm×450mm×645mm
(Lying Prone) 880mm×460mm×330mm

Weight:

60kg total weight (battery included)

Battery Performance:

Battery capacity 45Ah (2250Wh)
Voltage 58V

Endurance Ability:

Battery life 4-6h
Walking without load > 5h, and the mileage > 20km Walking with 20kg load > 4h, and the mileage> 15km

Wheeled Foot:

Optional

Load:

(Standing) Max. 120kg
Walking) 40kg

Continuous Stair Climbing:

20~25cm

Single Obstacle Crossing:

Climb up and down stairs of 40cm in forward direction

Climbing Angle:

45°

Running Speed:

6m/s (realized in special configurations, in practice there is a speed limit for security purposes)

Ditch Jumping Width:

0.5~1.2m

Max Jump Distance:

1.6m
